Description

Heavy-Duty Steel-Reinforced Plastic Pallet (1100x900x150mm)

Product Overview：heavy duty reinforced plastic pallet

Optimize your heavy-duty material handling and warehouse racking systems with our high-capacity Steel-Reinforced Plastic Pallet. Measuring 1100×900mm with a standard height of 150mm, this industrial pallet features advanced internal steel tube reinforcement channels running through both directions of its structure. This dual-direction reinforcement eliminates sagging or bowing under extreme load, making it exceptionally reliable for high-bay beam racks, automated conveyor systems, and intense logistics loops.

Key Features & Benefits：heavy duty reinforced plastic pallet

Dual-Direction Steel Tube Reinforcement: Embedded with heavy-duty steel bars extending horizontally through the runner base and the deck, ensuring unmatched rigidity and safety on warehouse pallet racks.
Industrial Polymer Construction: Molded from premium, high-density polymer materials that resist hard impacts, moisture, weak acids, and chemical exposure.
Hygienic Ventilated Grid Deck: The open mesh configuration encourages excellent airflow, prevents liquid or dust accumulation, and allows for rapid, thorough sanitization.
Seamless 4-Way Entry: Configured with highly accessible entry points from all four sides, streamlining operations for standard mechanical forklifts and manual hand jacks.
Conveyor-Friendly 3-Runner Base: Features three full-length bottom skids that deliver smooth, uninterrupted travel across automated roller conveyor lines and maximum stability when stacked.

Technical Specifications ：heavy-duty-steel-reinforced-plastic-pallet

Parameter	Specification
Dimensions (LxWxH)	1100 mm × 900 mm × 150 mm
Reinforcement	Cross-directional Internal Steel Tubes / Pipes
Deck Layout	Open Grid / Perforated Mesh
Base Design	3-Runner (Bottom Skids)
Entry Profile	4-Way Entry
Color	Industrial Blue

Meticulous Structural & Entry Dimensions：heavy duty reinforced plastic pallet

As detailed in the engineering drawing of “plastic pallet (3).jpg”, the dimensions provide exact clearances for standard warehouse machinery:

Length-wise (1100mm side): Features two fork entry openings measuring 200mm each, separated by a 350mm central runner block, and supported by 175mm outer edges.
Width-wise (900mm side): Configured with two 255mm wide entry clearances, a 170mm central runner wall, and 110mm outer corner blocks.
Total Height: Stands at 150mm, ensuring full compliance with international handling equipment standards.

Ideal Applications：heavy duty reinforced plastic pallet

Thanks to its robust steel-reinforced framework, this mid-size heavy-duty pallet is perfect for:

High-Bay Warehouse Racking: Securely supports heavy loads on open-beam racking configurations without structural deformation.
Automated Storage & Retrieval Systems (ASRS): Deflection-free design provides exact positioning and flawless tracking across automated conveyors.
Heavy Industrial & Automotive Parts: Easily bears the concentrated weight of heavy manufacturing parts, components, and raw materials.
Hygienic Supply Chains: Smooth, non-porous structure serves as an excellent replacement for wood in the food, beverage, and pharmaceutical distribution networks.
